Door hand grip Entero, square rosette

Hand grip ENTERO

SNi nickel matt grinded Design: Roman Ulich

A massive brass handle with a choice of 8 colours & surfaces, with a guarantee of 3-15 years, depending on the design, with quality mechanics M 2004, used for interior and exterior doors. News - natural brass with a lifetime guarantee.

Technical informations

MATERIAL

The massive brass, grinded and polished

AVAILABLE SURFACE FINISHES

nickel matt grinded, glossy chrome, titanium surfaces, brass natural

MOUNTING

Drilling with profi template M&T, screwing through with screw-together cases system, tightening torque 0.7-1 Nm depending on the door design according to the door manufacturer's recommendations, 5-6 Nm maximum tightening of the locking worm into the steel square.

MECHANICS

M 2004 with the reversible spring system and with the screw-together cases system

DIMENSIONAL APPLICATIONS

Standard for door thickness 38-45 mm, mounting options for door thickness from 38 to 126 mm

ACCESSORIES

The package includes:
- spindle
- set screw
- glue gel
- fasteners
- assembly instructions
- warranty card

WARRANTY

mechanics 3 years
surfaces 3 years nickel and chrome, titanium 15 years, brass natural lifetime guarantee

APPLICATIONS

according to the type of surface for the interior and exterior doors, for door weight up to 60 kg

SET

complete set including bottom lock rosettes

Rozměry

3D model for visualization

Door grip Entero (DWG)

Order numbers

ENTERO HAND GRIP	SNi nickel matt brushed	Cr glossy chrome	Ms brass natural	Ms-A brass antique	Ms-L brass polished	TiN-C titanium chrome matt	TiN-K titanium black matt	TiN-S titanum bronze matt	TiN-A titanium brass matt
ENTERO HAND GRIP	pair EAN	pair EAN	pair EAN	pair EAN	pair EAN	pair EAN	pair EAN	pair EAN	pair EAN
Key hole rosettes	68483	68537	052480	096750	052534	68636	68681	68582	68735
Cylindrical rosettes	68490	68544	052497	096767	052541	68643	68698	68599	68742
Toilet / bathroom	68506	68551	052503	096774	052558	68650	68704	68605	68759
fixed / turnable L	68520	68575	052527	096798	052572	68674	68728	68629	68773
fixed / turnable R	68513	68568	052510	096781	052565	68667	68711	68612	68766

Manufactory mechanics M 2004

About the mechanics

Mechanics M 2004 - designed, manufactured and assembled at M&T - with own patented slip system which prevents bending and cracking the door in lock area, simple and fast assembly.
