Hand grip long Minimal

Hand grip surfaces
9 surfaces

SNi

SNi - grinded

Ms-L

TiN-C

TiN-K

TiN-B

TiN-A

more about the surface

zoom

Unique design even on long hand grips

Technical informations

MATERIAL

Massive brass, grinded and polished

AVAILABLE SURFACE FINISHES

Nickel matt, nickel matt - grinded, glossy chrome, titanium surfaces, brass natural

MOUNTING

There are two mounting variants: Either in a blind hole, when it is necessary to specify the material of the door (plastic, wood, aluminium) or mounting with screws through the door, when there is a mounting possibility for a glass doors.

MECHANICS

From the inner side of the door there is a possibility of mounting handle Minimal with Mechanics M 2011 and with a spindle.

DIMENSIONAL APPLICATION

For a wooden, plastic and aluminium doors for the standard door thickness 38-126 mm, for glass doors 8-12 mm

ACCESSORIES

The package includes:
- fasteners according to the price list
- assembly instructions
- warranty card

WARRANTY

Handle mechanics 3 years
Surfaces 3 years nickel and chrome, titanium 15 years, brass nature life time guarantee

APPLICATIONS

According the type of surface for the interior and exterior doors, for door weight up to 60 kg

SET

Set of hand grips or one sided hand grip. It is needed to order the right mounting material according the type of door, eventually the spindle to one sided handle.

Rozměry

3D model for visualization

Hand grip long Minimal (DWG)

Order numbers

HAND GRIP LONG MINIMAL	SNi nickel matt	SNi nickel matt brushed	Cr glossy chrome	Ms brass natural	Ms-A brass antique	Ms-L brass polished	Cr-K chrome black brushed 3D	Ms-D brass old wood	TiN-M titanium cooper grinded
HAND GRIP LONG MINIMAL	EAN	EAN	EAN	EAN	EAN	EAN	EAN	EAN	EAN
One-sided	pc 002775	pc 002782	pc 002799	pc 058826	pc 242430	pc 058840	pc 088045	pc 242454	pc 242492
Double sided	pair 002706	pair 002713	pair 002720	pair 058819	pair 242447	pair 058833	pair 088038	pair 242485	pair 242508

HAND GRIP LONG MINIMAL	TiN-C titanium chrome matt	TiN-K titanium black matt	TiN-G titanium graphite matt	TiN-B titanium brown matt	TiN-S titanum bronze matt	TiN-A titanium brass matt	K-industrial	Wh white matt
HAND GRIP LONG MINIMAL	EAN	EAN	EAN	EAN	EAN	EAN	EAN	EAN
One-sided	pc 002805	pc 002829	pc 242461	pc 002812	pc 242515	pc 002836	pc 242539	pc 242683
Double sided	pair 002737	pair 002751	pair 242478	pair 002744	pair 242522	pair 002768	pair 242676	pair 242690

	MOUNTING MATERIAL FOR HAND GRIPS
	MOUNTING MATERIAL FOR HAND GRIPS	EAN
	One-sided to blind hole - wood	030228
	One-sided to blind hole - aluminium	030211
	One-sided to blind hole - plastic	030204
	One-sided for glas with screwing through and blind cover	003031
	One-sided with screwing through and blind cover	003024
	Double sided	003048
	Double sided for glass	003055

Uváděné ceny - doporučené konečné ceny v € bez DPH.

SPARE PARTS

We supply you with separate the most used components and thus repeatedly extend the service life of the entire fitting.

EXTENDED WARRANTY

We have guarantee on all products at least 3 years, on mechanics 5 years, titan surfaces 15 years, handles from massive natural brass is lifetime guarantee.

REPEATED PRODUCTION

You like one model and you will want to buy the same model in years? No problem. As the main service for the customer, we have been offering all manufactured handle models in a long term.
