Handle 225 mm / HS portal Maximal

Handle 225 mm MAXIMAL to HS portal systems

SNi nickel matt Design: Roman Ulich

HS portals made of massive brass with a choice of 9 colours & surfaces, with a guarantee of 3-15 years, depending on the design, used for wooden and aluminium windows. You can choose of different fillings in designs metal, leather, veneer, effectg "glass", colours RAL.
News - natural brass with a lifetime guarantee.

Handle surfaces
9 surfaces

SNi

SNi - grinded

Ms-L

TiN-C

TiN-K

TiN-B

TiN-A

more about the surface

Extraordinery design of HS portals M&T

MATERIAL

Massive brass, grinded and polished

AVAILABLE SURFACE FINISHES

Nickel matt, nickel matt - grinded, glossy chrome, titanium surfaces, brass natural

MOUNTING

Using the positioning mechanism and screws into the window frame, eventually to a pair of opposed through a window frame.

MECHANICS

The positioning mechanism with a very strong spindle 10x10 mm made of stainless steel.

DIMENSIONAL APPLICATION

For a wooden, aluminium or plastic windows for the frame thickness 55-120 mm. The frame thickness is needed to specify exactly.

ACCESSORIES

The package includes:
- fasteners
- positioning mechanism fixed to a handle
- cover plate of mechanism
- strong spindle
- assembly instructions
- warranty card

WARRANTY

Mechanics 3 years.
Surfaces 3 years nickel and chrome, titanium 15 years, brass natural life time guarantee

APPLICATIONS

For all of window types with the HS portal system.

SET

One sided window handle with a cover plate or two-sided design. The filling is to order extra.

Rozměry

Order numbers

HANDLE 225 MM MAXIMAL	SNi nickel matt	SNi nickel matt brushed	Cr glossy chrome	Ms brass natural	Ms-L brass polished	TiN-C titanium chrome matt	TiN-K titanium black matt	TiN-B titanium brown matt	TiN-A titanium brass matt
HANDLE 225 MM MAXIMAL	EAN	EAN	EAN	EAN	EAN	EAN	EAN	EAN	EAN
One-sided	pc 002270	pc 002287	pc 002294	pc 059793	pc 059823	pc 002300	pc 002324	pc 002317	pc 002331
One-sided with cylindrical hole	pc 064780	pc 064797	pc 064803	pc 064858	pc 064865	pc 064810	pc 064834	pc 064827	pc 064841
Double sided	pair 002348	pair 002355	pair 002362	pair 059809	pair 059830	pair 002379	pair 002393	pair 002386	pair 002409
Double sided with cylindrical hole	pair 002416	pair 002423	pair 002430	pair 059816	pair 059847	pair 002447	pair 002461	pair 002454	pair 002478

PULL HANDLE MINIMAL EXTERNAL	SNi nickel matt	SNi nickel matt brushed	Cr glossy chrome	Ms brass natural	Ms-L brass polished	Cr-K chrome black brushed 3D	Ms-D brass old wood	TiN-C titanium chrome matt	TiN-K titanium black matt
PULL HANDLE MINIMAL EXTERNAL	EAN	EAN	EAN	EAN	EAN	EAN	EAN	EAN	EAN
External flush handle	pc 002201	pc 002218	pc 002225	pc 059915	pc 059939	pc 087970	pc 200669	pc 002232	pc 002256
Flush handle with cylindrical hole	pc 022544	pc 022551	pc 022568	pc 059922	pc 059946	pc 087987	pc 200676	pc 022575	pc 022599

PULL HANDLE MINIMAL EXTERNAL	TiN-B titanium brown matt	TiN-S titanum bronze matt	TiN-A titanium brass matt
PULL HANDLE MINIMAL EXTERNAL	EAN	EAN	EAN
External flush handle	pc 002249	pc 241327	pc 002263
Flush handle with cylindrical hole	pc 022582	pc 241334	pc 022605

SPARE PARTS

We supply you with separate the most used components and thus repeatedly extend the service life of the entire fitting.

EXTENDED WARRANTY

We have guarantee on all products at least 3 years, on mechanics 5 years, titan surfaces 15 years, handles from massive natural brass is lifetime guarantee.

REPEATED PRODUCTION

You like one model and you will want to buy the same model in years? No problem. As the main service for the customer, we have been offering all manufactured handle models in a long term.

SUSTAINABILITY

we protect our planet, so we design and manufacture products products with a lifetime warranty - innovative products that will survive us.

Positioning mechanism of HS portals

Positioning mechanism with 3 positions

Metal mechanism with an inner metal construction guaranteeing an exact positionability in 3 positions and a firm fixation using a very strog spindle 10x10 mm made of stainless steel. With a mounting for frame thickness of 55 - 120 mm.
