Handle 225 mm / HS portal Minimal

Handle 225 mm MINIMAL to HS portal systems

TiN-K titanium black matt Design: Roman Ulich

HS portals made of massive brass with a choice of 9 colours & surfaces, with a guarantee of 3-15 years, depending on the design, used for wooden and aluminium windows.
News - natural brass with a lifetime guarantee.

Handle surfaces
9 surfaces

SNi

SNi - grinded

Ms-L

TiN-C

TiN-K

TiN-B

TiN-A

more about the surface

Extraordinery design of HS portals

MATERIAL

Massive brass, grinded and polished

AVAILABLE SURFACE FINISHES

Nickel matt, nickel matt - grinded, glossy chrome, titanium surfaces, brass natural

MOUNTING

Using the positioning mechanism and screws into the window frame, eventually to a pair of opposed through a window frame.

MECHANICS

The positioning mechanism with a very strong spindle 10x10 mm made of stainless steel.

DIMENSIONAL APPLICATION

For a wooden, aluminium or plastic windows for the frame thickness 55-120 mm. The frame thickness is needed to specify exactly.

ACCESSORIES

The package includes:
- fasteners
- positioning mechanism fixed to a handle
- cover plate of mechanism
- strong spindle
- assembly instructions
- warranty card

WARRANTY

Mechanics 3 years.
Surfaces 3 years nickel and chrome, titanium 15 years, brass natural life time guarantee

APPLICATIONS

For all of window types with the HS portal system.

SET

One sided window handle with a cover plate or two-sided design.

Rozměry

Order numbers

HANDLE 225 MM MINIMAL	SNi nickel matt	SNi nickel matt brushed	Cr glossy chrome	Ms brass natural	Ms-A brass antique	Ms-L brass polished	Cr-K chrome black brushed 3D	Ms-D brass old wood	TiN-C titanium chrome matt
HANDLE 225 MM MINIMAL	EAN	EAN	EAN	EAN	EAN	EAN	EAN	EAN	EAN
One-sided	pc 001990	pc 002003	pc 002010	pc 059731	pc 253597	pc 059762	pc 087949	pc 200621	pc 002027
One-sided with cylindrical hole	pc 064698	pc 064704	pc 064711	pc 064766	pc 253603	pc 064773	-	pc 200638	pc 064728
Double sided	pair 002065	pair 002072	pair 002089	pair 059748	pair 253610	pair 059779	pair 087956	pair 200645	pair 002096
Double sided with cylindrical hole	pair 002133	pair 002140	pair 002157	pair 059755	pair 253627	pair 059786	pair 087963	pair 200652	pair 002164

HANDLE 225 MM MINIMAL	TiN-K titanium black matt	TiN-B titanium brown matt	TiN-S titanum bronze matt	TiN-A titanium brass matt	K-industrial	Wh white matt
HANDLE 225 MM MINIMAL	EAN	EAN	EAN	EAN	EAN	EAN
One-sided	pc 002041	pc 002034	pc 241280	pc 002058	pc 250725	pc 250848
One-sided with cylindrical hole	pc 064742	pc 064735	pc 241297	pc 064759	-	-
Double sided	pair 002119	pair 002102	pair 241303	pair 002126	-	-
Double sided with cylindrical hole	pair 002188	pair 002171	pair 241310	pair 002195	-	-

PULL HANDLE MINIMAL EXTERNAL	SNi nickel matt	SNi nickel matt brushed	Cr glossy chrome	Ms brass natural	Ms-L brass polished	Cr-K chrome black brushed 3D	Ms-D brass old wood	TiN-C titanium chrome matt	TiN-K titanium black matt
PULL HANDLE MINIMAL EXTERNAL	EAN	EAN	EAN	EAN	EAN	EAN	EAN	EAN	EAN
External flush handle	pc 002201	pc 002218	pc 002225	pc 059915	pc 059939	pc 087970	pc 200669	pc 002232	pc 002256
Flush handle with cylindrical hole	pc 022544	pc 022551	pc 022568	pc 059922	pc 059946	pc 087987	pc 200676	pc 022575	pc 022599

PULL HANDLE MINIMAL EXTERNAL	TiN-B titanium brown matt	TiN-S titanum bronze matt	TiN-A titanium brass matt
PULL HANDLE MINIMAL EXTERNAL	EAN	EAN	EAN
External flush handle	pc 002249	pc 241327	pc 002263
Flush handle with cylindrical hole	pc 022582	pc 241334	pc 022605

SPARE PARTS

We supply you with separate the most used components and thus repeatedly extend the service life of the entire fitting.

EXTENDED WARRANTY

We have guarantee on all products at least 3 years, on mechanics 5 years, titan surfaces 15 years, handles from massive natural brass is lifetime guarantee.

REPEATED PRODUCTION

You like one model and you will want to buy the same model in years? No problem. As the main service for the customer, we have been offering all manufactured handle models in a long term.

SUSTAINABILITY

we protect our planet, so we design and manufacture products products with a lifetime warranty - innovative products that will survive us.

Positioning mechanism of HS portals

Positioning mechanism with 3 positions

Metal mechanism with an inner metal construction guaranteeing an exact positionability in 3 positions and a firm fixation using a very strog spindle 10x10 mm made of stainless steel. With a mounting for frame thickness of 55 - 120 mm.
