Stainless steel window handle Iconic, flat rosette

Window handle ICONIC

NRz stainless steel polished Design: Bára Škorpilová

Stainless steel window handle with a choice of 9 surfaces & colours, with a warranty of 5 - 15 years depending on the type of design, for use on timber, aluminium and plastic windows.

Handle surfaces

9 surfaces

NRz

TiN-C

TiN-K

TiN-G

TiN-B

TiN-S

TiN-A

K-industrial

more about the surface

Selection all of designs and surfaces of window handles

MATERIÁL

Solid stainless steel

AVAILABLE SURFACE FINISHES

Stainless steel ground, titanium surfaces

MOUNTING

Using the window positioning mechanism into the window frame, providing a set screw for the handle mechanism.

MECHANIKA

The positioning mechanism with 3 positions with a spindle 7x7 mm in the window frame, the standard length is 40 mm.

DIMENSIONAL APPLICATION

For a wooden, plastic and aluminium windows with a spindle 40 mm. Part of the mechanics is inserted in the window frame.

ACCESSORIES

The package includes:
- fasteners
- positioning mechanism
- assembly instructions
- warranty card

WARRANTY

Mechanics 3 years.
Stainless steel 5 years, black matt structured 5 years, titanium 15 years

APPLICATIONS

For all of window types with a standard positioning mechanism.

SET

Window handle with a cover rosette and a positioning mechanism.

Rozměry

Dimensions of the positioning mechnism

Požární odolnost

Order numbers

WINDOWS HANDLE ICONIC	NRz stainless steel - brushed	TiN-C titanium chrome matt	TiN-K titanium black matt	TiN-G titanium graphite matt	TiN-B titanium brown matt	TiN-S titanum bronze matt	TiN-A titanium brass matt
WINDOWS HANDLE ICONIC	pc EAN	pc EAN	pc EAN	pc EAN	pc EAN	pc EAN	pc EAN
4 positions R	184006	184020	184044	184068	184082	184105	184129
4 positions L	184013	184037	184051	184075	184099	184112	184136

The window mechanism is part of the window handle accessory.

SPARE PARTS

We supply you with separate the most used components and thus repeatedly extend the service life of the entire fitting.

EXTENDED WARRANTY

We have guarantee on all products at least 3 years, on mechanics 5 years, titan surfaces 15 years, handles from massive natural brass is lifetime guarantee.

REPEATED PRODUCTION

You like one model and you will want to buy the same model in years? No problem. As the main service for the customer, we have been offering all manufactured handle models in a long term.

SUSTAINABILITY

we protect our planet, so we design and manufacture products products with a lifetime warranty - innovative products that will survive us.

Positioning mechanism of window handles

Positioning mechanism of the flat rosette

Metal mechanism with an inner metal construction guaranteeing an exact positionability in 3 positions and firm fixation of the window handle in the mechanism. A part of the mechanism is sink into the window frame.
